Worm Gear 3000 kg Hand Winch SS304 / SS316

3000 kg Stainless Steel Worm Gear Hand Winch

The Worm Gear 3000 kg Hand Winch SS304 / SS316 is a heavy-duty stainless steel manual winch designed for controlled lifting and pulling applications. Its worm gear drive provides high torque, smooth operation, and stable load control, making it suitable for demanding industrial and corrosion-prone environments.

Get A Quote

Unique Features :

Available in SS304 / SS316 material
Heavy-duty worm gear drive
High torque with controlled operation
Corrosion-resistant stainless-steel construction
Suitable for industrial, outdoor, and marine applications

Specifications :

Type : Worm Gear Hand Winch

Operation : Manual

Finish : Epoxy / Powder Coated

Application : Heavy-duty lifting and pulling

Material : SS304 / SS316

Parameter	Details
Capacity - 1st Layer	3000 kg
Capacity - 3rd Layer	2200 kg
Capacity - Top Layer	1700 kg
Wire Rope Diameter-Ø	14 mm
Wire Rope Length	30 mtr
Weight	120 kg without wire rope
Safety Factor	1.5
Brake Type	Load Pressure Brake with Ratchet Pawl Mechanism
Load Holding	In any position
