Portable Davit Crane - 2000 kg

Material : Mild Steel / HDG / Epoxy Painted

The Extra Heavy-Duty Portable Davit Crane is a top-tier lifting solution engineered specifically for high-capacity industrial applications and rigorous load-handling tasks. Fabricated from premium, ultra-strong mild steel, this crane provides maximum structural rigidity and stability required for moving heavy materials safely.

Get A Quote

Unique Features :

Extra heavy-duty portable davit crane design for industrial lifting applications
Strong mild steel construction suitable for heavy load handling
Available with Hot Dip Galvanized or Epoxy Painted finish for corrosion protection
Telescopic boom arrangement for adjustable working reach
360° manual rotation for easy load positioning and controlled handling

Specifications :

Type : Portable Davit Crane

Operation : Manual Winch Operated

Finish : Hot Dip Galvanized / Epoxy Painted

Application : Heavy-duty lifting / lowering / load positioning

Technical Specifications :

Parameter	Details
Capacity	2000 kg
Material	Mild Steel
Boom Length	1 mtr to 2.5 mtr
Rotation	360° Manual Rotation
Operation	Manual Winch Operated
Wire Rope Diameter-Ø	12 mm / 14 mm, as per design
Mounting Arrangement	Heavy-Duty Base Plate with Anchor Bolts
Finish	Hot Dip Galvanized / Epoxy Painted
Load Holding	Manual Winch with Brake Arrangement
Testing	Load Testing / TPI can be provided as required
