Worm Gear 250 kg Hand Winch

Manual Worm Gear Winch (250 kg)

The Worm Gear 250 kg Hand Winch is a manual winch designed for controlled lifting and pulling applications. Its worm gear mechanism provides smooth operation, better load control, and stable holding, making it suitable for light to medium-duty material handling work.

Get A Quote

Unique Features :

Worm gear drive for smooth and controlled operation
Better load holding and stability
Compact and robust design
Suitable for lifting and pulling applications
Epoxy / powder coated finish

Specifications :

Type : Worm Gear Hand Winch

Operation : Manual

Finish : Epoxy / Powder Coated

Application : Light / medium-duty lifting and pulling

Parameter	Details
Capacity - 1st Layer	250 kg
Capacity - 3rd Layer	170 kg
Capacity - Top Layer	100 kg
Wire Rope Diameter-Ø	5 mm
Wire Rope Length	20 mtr
Weight	7 kg without wire rope
Safety Factor	1.5
Brake Type	Self-Breaking Gear Mechanism + Load Pressure Brake with Ratchet Pawl Mechanism
Load Holding	In any position
